After every cleaning cycle:
1. Unplug power to the cleaner at the control
unit.
2. Remove the cleaner from the pool and
untangle all kinks and coils in the oating
cable starting at the cleaner head (see Figure
23). Lay cable in sunlight to loosen tangling
memory in the cable.
3. Plug power cord back into control unit and
store cleaner on the caddy out of direct
sunlight for next use.
Figure 23. Untangle the Floating cable
Cleaner
Control Unit /Caddy
IMPORTANT
The floating cable may become tangled if correct
procedure is not followed after each cleaning cycle.
Do not leave the cleaner unattended for prolonged
periods, always spread the oating cable over the pool,
and follow the procedure to avoid excessive tangling.
4.2 Check for Brush Wear
The cleaner is tted with PVC brushes in front and
rear. There are raised grooves that are ''wear'' indicators
on the brushes located next to the tab connectors (see
Figure 24). As brushes wear out, the raised groove will
atten and smoothen into the track.
Figure 24. Wear Indicators
To maintain optimal cleaner performance, replace the
brushes as soon as one of the wear indicators is smooth
or worn down (even if the blade wear is not even). It is
recommended that brushes are routinely replaced every
two (2) years.
4.3 Storing the Cleaner
Do not let your cleaner dry in direct sunlight near the
pool.
1. Starting at the cleaner head. Remove all coils
and tangles from the cable (Figure 25).
2. Store the cleaner out of direct sunlight.
Figure 25. Untangle the Floating Cable
14
H0574000_REVA
