ERSATZTEILE / SPARE PARTS
ZIPPER MASCHINEN GmbH www.zipper-maschinen.at 38
ZI-STE1000INV
17.3 Ersatzteilliste / Spare parts list
No. Description Qty.
No. Description Qty.
1 M5*16 screw 4
33 Intake manifold 1
2 Panel 1
34 Air filter sponge 1
3 Front cover 1
35 bottom air duct 1
4 lighter 1
36 left air duct 1
5 ECO switch 1
37 left cover 1
6 AC socket 1
38 Overhaul cover 1
7 DC socket -3A 1
39 M6*14 screw 1
8 Inverter 1
40 Handle / cover 1
9 Inverter shock pad 2
41 M5*14 screw 1
10 Engine shock pad 4
42 Pull rope cover 1
11 Recoil starter 1
43 M4*12 screw 1
12
Bridge Rectifier（AC-DC）
1
44 Master switch 1
13 Air duct front cover 1
45 M5*20 Self tapping screw 4
14 Fan 1
46 φ6 shim 4
15 Flywheel 1
47 Generator damping pad 4
16 Stator 1
48 Touch switch 1
17 Ignition trigger 1
49 Touch switch cover plate 1
18 Engine 1
50 Carburetor tube 1
19 Ignition coils 1
51 fuel pump 1
20 M6*120 screw 2
52 φ9.5Hoop (steel wire clamp) 3
21 M5*14 screw 2
53 Crankshaft air return pipe 1
22 Spark plug cover 1
54 Fuel switch pipe 1
23 Right cover 1
55 φ8 Hoop (steel wire clamp) 2
24 M5 clip nut 8
56 Fuel switch 1
25 Right air duct 1
57 Fuel tank pipe 1
26 Muffler elbow gasket 2
58 φ10.5 Hoop (steel wire clamp) 1
27 Muffler elbow 1
59 Fuel outlet strainer 1
28 Carburetor 1
60 Fuel inlet strainer 1
29 Muffler 1
61 Fuel tank damping pad 1
30 Back cover rubber seal 1
62 Fuel tank 1
31 M5*16 screw 4
63 Fuel tank cap 1
32 Back cover 1
64 Fuel tank filler gasket 1
