8
WE WOULD LIKE TO THANK YOU FOR CHOOSING ZELMER. WE WISH THE PRODUCT PERFORMS
TO YOUR SATISFACTION AND PLEASURE.
WARNING
Please read the instructions for use carefully prior to using the product. store these in a safe place for
future reference.
DESCRIPTION
1. On / Off button
2. Cord rewind button
3. Speed control
4. Handle
5. Telescopic tube
6. Hose
7. SAFBAG
8. Accessory compartment
9. Outlet filter cover
10. 2 in 1 brush
11. Upholstery nozzle
12. Crevice nozzle
13. Round brush
14. Turbo brush
15. Parquet brush
16 Filter ( HEPA 13 or ULTRA16)
SAFETY INSTRUCTIONS
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without
supervision.
If the supply cord is damaged it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Plug must be removed from socket-outlet before cleaning
or maintaining the appliance.
This appliance is intended for use at a maximum altitude
of 2000m above sea level.
IMPORTANT WARNINGS
Prior to plugging in the product, check that your mains voltage is the same as the one indicated on the
product label.
The mains connection cable must not be tangled or wrapped around the product during use.
Do not pull on the connection cord in order to unplug it.
Do not use, connect or disconnect the device to the mains with your hands or feet wet.
Proceed according to the conservation and cleaning section of this manual for cleaning.
Unplug the product immediately from the mains in the event of any breakdown or damage and contact an
authorised Technical support service.
In order to prevent any risk of danger, do not open the device. Only qualified technical personnel from the
brand´s Official Technical support service may carry out repairs or procedures on the device.
Any incorrect use or improper handling of the product shall render the warranty null and void. Only an
authorised technical support service centre may carry out repairs on this product.
This appliance is designed exclusively for domestic use, in no case should be a commercial or industrial
use. In case of misuse or tampering with the product, it will be out of warranty.
Do not use the appliance to vacuum liquids (water, etc), sharp objects (pins, pins, nails, glass, etc),
incandescent objects (matches, cigarettes)
Never use the turbo brush to: Polish floors, suck (Liquids, wet or damp dust, hot ash, burning objects, such
as cigarettes, matches, sharp and hard items, such us: razors, pins, thumbtacks, pieces of glass, etc),
flour, cement, plaster, printer or photocopier toner, etc.
B&B TRENDS SL. disclaims all liability for damages that may occur to people, animals or objects, for
the non-observance of these warnings.
Vacuum cleaner types
Vacuum cleaner Operation
1. Connect the hose to vacuum cleaner: insert the hose end into the hose socket.
2. Adjust the length of the telescopic suction tube by sliding the slider according to the arrow and pull
out/pull the tube together.
3. Connect the different nozzle or brush to the telescopic tube for different cleaning purpose.
4. The vacuum cleaner is equipped with an accessory compartment. In order to open it pull the compart-
ment cover up.
5. Pull the plug and cord out of the vacuum cleaner.
Before operation make sure that the SAFBAG is installed in the vacuum cleaner chamber and that inlet
filter
and the outlet filter is installed in the appliance.
6. Switch on the vacuum cleaner by pressing On/Off
7. The vacuum cleaner is equipped with electronic power regulator in order to reduce or increase the
power.
Vacuum cleaner accessories
Parquet brush
Used to clean sensitive surfaces such us floor panels, parquet, marble and like that. Delicate and soft
natural bristles ensure maximum vacuum effectiveness and protects against scratching the cleaned
surface.
Turbo brush
Used to clean hard floors or floors where you need extra cleaning power. The turbo brush contains a
rotating brush to lift and beat your carpet or fabric as you vacuum.
Vacuum cleaner Filters
Inlet filter
Before changing the inlet filter make sure the vacuum cleaner is switched off
1. Open the front cover of the vacuum cleaner
2. Remove the filter
3. Replace it with the new one
4. Close the front cover of the vacuum cleaner
Outlet filter ( HEPA 13 or ULTRA 16)
1. In order to replace the outlet filter, open the accessory compartment
2. Press the blocking mechanism of the outlet filter cover and remove it
3. Remove the outlet filter and replace it for a new one. The filter assure circa 1 year of effective usage
4. Place the outlet filter cover back.
5. Close the accessory compartment
Safbag dust bag disassembly
1. The vacuum cleaner is equipped with safety valve located in chamber of dust container (bag). It opens
automatically in case of total stopping of suction hose or total stopping of equipment elements connected
thereto, as well as in case of overfill of dust bag. After opening the valve one can hear characteristic “whirr”
sound inside the vacuum cleaner.
2. Switch off the vacuum cleaner
3. Pull out the hose
4. Open the front cover
5. Replace the SAFBAG for a new one
6. Close the cover
Do not start cleaning without an installed SAFBAG bag.
End of Operation
1. Switch off the vacuum cleaner by pressing the button on/off
2. Unplug the appliance
3. Wind the cord by pressing the cord rewind button
4. Disconnect the brush or nozzle from the suction tube
5. Disconnect the hose from the vacuum cleaner
6. The vacuum cleaner may be stored vertically or horizontally.
PRODUCT DISPOSAL
This product complies with European Directive 2012/19/EU on electrical and electronic devices,
known as WEEE (Waste Electrical and Electronic Equipment), provides the legal framework
applicable in the European Union for the disposal and reuse of waste electronic and electrical
devices. Do not dispose of this product in the bin, instead going to the electrical and electronic
waste collection centre closest to your home
EN
MODEL
ADJUSTABLE SUCTION POWER
DUST BAG
OUTLET FILTER
SUCTION TUBE
SUCTION HOSE
UPHOLSTERY NOZZLE
CREVICE NOZZLE
ROUND BRUSH
PARQUET BRUSH
TURBO BRUSH
ZVC3500R
ZVC3501R
ZVC3501T
ZVC3502N
ZVC3506B
SAFBAG 1 PIECE
SAFBAG 1 PIECE
SAFBAG 1 PIECE
SAFBAG 1 PIECE
SAFBAG 1 PIECE
HEPA 13
HEPA 13
HEPA 13
HEPA 13
ULTRA 16
Telescopic
Telescopic
Telescopic
Telescopic
Telescopic
+
Flexi wired
Flexi wired
Flexi wired
Flexi wired
1 2 3 4 5 6 7 8 9 10 11
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
-
+
+
-
+
-
-
-
+
+
