Install Hardware Options
57
Installing the Label Dispenser
The standard bezel must be removed and DC input power disconnected before the Label Dispenser can
be installed. Go to Removing the Standard Bezel on page 56.
1. Place the label dispenser module and printer right side up with the top of the module 12.5 mm (0.5 in.)
below the bottom of the top cover.
2. Center and push the module into the front of the printer and slide it up until it stops.
3. Turn the printer upside down and attach the module to the printer with the two screws using the T10
wrench.
NOTE: For optimal printer performance, update the printer’s firmware after installing options or
immediately after the printer’s initial setup. Go to Updating Printer Firmware on page 271.
