36
Status Light Descriptions
Status Light Error Resolutions
The following Status Error Light Resolution numbers correspond to the Status Light Description table
above.
1. The printer is not receiving power.
• Have you turned on the printer power? Check power connections from the wall outlet to the
power supply, and from the power supply to the printer. See Loading Roll Media.
• Disconnect the printer from the wall outlet for 30 seconds and then reconnect the printer to
power.
2. The printer is on and in an idle state.
• No action necessary.
3. The printer is receiving data.
• When data transfer completes, the status LED turns green and the printer will resume operation.
4. The media path alert.
• Media is Out - Open the cover and verify media is out. Remove the empty label roll if using roll
media. Replace the media. Follow the instructions for Loading Roll Media and then press the
Feed button to resume printing.
• Cover not latched - The cover (and printhead) is open. Open and close the top cover firmly and
then press the Feed button to resume printing.
• Head Open Sensor needs cleaning - The optical sensor and reflector are dirty. and need
cleaning, see Sensor Cleaning.
• Media is not being sensed - The media sensors are blocked or dirty, and need cleaning, see
Sensor Cleaning.
5. The printer is paused.
• Press the Feed button to resume printing.
What the Status Light is Telling You
LED Status and Color Printer Status Resolution Number
Off Off 1
Solid Green On 2
Flashing Green Normal Operation 3
Flashing Red Stopped 4
Double Flashing Green Paused 5
Flashing Amber Paused 6
Alternately Flashing Green and Red Needs Service 7
Rapid Red Flashing Media Not Sensing Properly 8
