Device Description and Technical Specifications 7 - 5
Power Supply
The device model is displayed on the device type plate.
Power Supply Fuses
The symbol for the fuse is FA. You will find the exact position on the sticker located on the connection plate.
DC Power Pack
12/24 VDC
30 W internal
Type DC-11
12/24 VDC nominal
Voltage range: 9 to 36 VDC
Voltage drops of up to 5 V and up to 20 seconds can be bridged
Bridging of power failures of 5 ms at 12 VDC
Start voltage at least 9 VDC
Galvanically isolated
Maximum output: 30 W
Withstands bursts up to 2 kV
Nominal current of 4.2 / 1.0 A
Connection to SELV circuit* only
DC Power Pack
24/48 VDC
30 W internal
Type DC-12
24/48 VDC nominal
Voltage range: 18 to 60 VDC
Voltage drops of up to 5 V and up to 20 seconds can be bridged
Bridging of power failures of 5 ms
Galvanically isolated
Maximum output: 30 W
Withstands bursts up to 2 kV
Nominal current of 2.5 A / 1.2 A
Connection to SELV circuit* only
Power Consumption 8585/10: typically 20 W
Standby: typically 1 W
(8585/10 with DC power pack in standby mode)
* The SELV circuit is a secondary circuit that is designed and protected so that its voltages will not exceed
a safe value both when operating correctly or if a single error occurs.
Power Supply Fuse Type Examples
DC-11 5 x 20 mm T 10 A Bussman S505-10A
H / 250 V Wickmann 181-10A
Littelfuse 215 10
Siba 70 007 65 10A
Elu 179200 10A
