3 - 6 8585/8595 Vehicle-Mount Computer User Guide
Figure 3-2
Antenna cap 8585
To access this Service USB interface, you need to remove the antenna cap from the unit.
Figure 3-3
Service USB under the antenna cap
Unfasten antenna cap from unit and refasten it:
1. Unscrew the two screws from the antenna cap with an Allen key (size 3 mm).
2. Lift the antenna cap carefully to avoid pulling on the antenna connection cables (max. 2 to 3 cm).
Antenna cap
and Service USB interface
Caution:
Property
Damage
Incorrect or improper removal and fastening of the antenna cap can impair the function of the entire
8585 system. These actions, or if the 8585 is operated with the antenna cap/service USB interface open
for a longer period of time than required for service tasks, will invalidate any warranty provided by
Zebra.The service USB interface may only be used for maintenance purposes, e.g. to load software
updates. The antenna cap/service USB interface may only remain open for the duration of the service
work. It may only be opened and closed by qualified technical personnel.
No objects or fluids may be introduced into the 8585 while the antenna cap and the USB interface
are open.
Only when the antenna cap/service USB interface is properly closed again may operation be resumed;
protection class is then ensured again.
Do not pull the antenna connection cable too far out of the unit, catch it, or cut it.
