3 - 4 8585/8595 Vehicle-Mount Computer User Guide
should be fused. On positive chassis vehicles, the negative lead should be fused. On floating chassis vehicles,
the positive and negative leads must be fused. Any additional wiring (minimum 18 gauge), connectors or
disconnects used should be rated for at least 90 VDC, 10 A.
When connecting PN 13985-301, ensure that the screen blanking wires (clearly labelled) and the power wires
(red/black leads) are reliably secured away from each other, or are separated with reliably secured certified
insulation. Minimum 2.8 mm distance, or 0.4mm distance through insulation is required for the separation.
The red lead of the power cable attaches to the positive vehicle supply. The black lead connects to the nega-
tive supply – this should be connected to a proper terminal block and not to the vehicle body. The external wire
of the power adapter cable is connected to the ground lug of the 8585/8595 terminal connector bay and to the
vehicle chassis.
You have the option of connecting power before or after the key switch. The 8585/8595 should not be shut off
by simply removing the power. If it is wired after the key switch, the operator must shut down the 8585/8595
using the Windows shutdown procedure before turning off the vehicle. If it is wired before the key switch, then
to avoid excessive drain on the vehicle battery, either the operator should shut it down when the vehicle is to be
left off for an extended period, or the ignition cable shutdown wire should be connected and the 8585/8595
configured to shutdown automatically.
If an unfused power source must be used, a fuse assembly (PN 19440-300) and diode/choke assembly
(PN 30723-301A) must be added to the extension power cable (the fuse, diode/choke and instructions are
supplied with the cable). Use only a 10A slow blow UL approved fuse in the fuse assembly. The fuse assembly
must be located as close as practical to the DC supply, and shall connect to either the positive, or negative side
of the DC supply, depending on the chassis grounding scheme. For floating chassis vehicles, an additional 10
A slow blow UL approved fuse (fuse assembly PN 19440-300) should be installed on both power supply lines.
To safely wire power to the 8585/8595, review these guidelines and follow the instructions that apply to your
needs:
• When connecting the cable (PN 13985-301) to the screen blanking cable (PN 1616303-001), the wire pair
on the 13985-301 labelled “screen blanking” connect to the screen blanking control device, which must
provide an isolated relay closure across the pair.
• When connecting the cable (PN 13985-301) to the ignition cable (PN 1616302-001), the wire pair labelled
“screen blanking” on the 13985-301 has a different function; the red wire must connect to a DC+ voltage
source switched on by the ignition, while the black wire may connect to DC- or be taped off.
• Note that only the ignition function is supported by the UPS (models PS1110/PS1120), not the
screen blanking. If both screen blanking and ignition are to be used on the same 8585/8595, contact Zebra
for details.
Position of the 8585 in the Vehicle
In the vehicle, the driver's field of view must be kept free.
If a keyboard and scanner are installed on the 8585, please plan sufficient space.
No part of the 8585 system may project beyond the vehicle.
Overview of the Assembly Steps
Before fastening the 8585 to the vehicle:
• The shutdown automation must be configured.
• The forklift must be prepared (connection to ignition, correct voltage, etc.).
We recommend the following installation sequence:
1. Fasten the bracket to the vehicle.
