1) Electrical & Physical Speci󰘰cations

AC Input Range

Voltage 100~240VAC

Vout

Output Load Rating

Combined

Power

Frequency 50Hz ~ 60Hz I

min

max

peak

AC Input Current

100VAC

10A~5A

+3.3V 0A 20A

100W

750W

240VAC +5V 0A 20A

PFC Type Active PFC +12V 0A 62.5A 750W

Power Factor Correction Max 99% -12V 0A 0.3A 3.6W

Inrush Current Limit

(@ Cold Start at 25℃)

100VAC

Max 100A

+5VSB 0A 3A 15W

240VAC Ambient Temperature

E󰘲ciency Max 90% @ 115VAC, Typical load Operation 0 ~ +40℃

DC Output Voltage

Regulation

Vout Regulation Range

Full

Load

Storage -20 ~ +70℃

+3.3VDC ±5% +3.14 ~ +3.47V Ambient Humidity

+5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 85% RH

+12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95% RH

-12VDC ±10% -10.8 ~ -13.2V Dimensions 140(L) X 150(W) X 86(H) mm

+5VSB ±5% +4.75 ~ +5.25V Weight 2.3Kg

DC Output Ripple

& Noise

Vout Standard Range

Full

Load

Protection Funtions

+3.3VDC 50mV Over-Current Protection (OCP)

+5VDC 50mV Over-Voltage Protection (OVP)

+12VDC 120mV Over-Power Protection (OPP)

-12VDC 120mV Over-Temperature Protection (OTP)

+5VSB 50mV Under-Voltage Protection (UVP)

Short-Circuit Protection (SCP)

2. ZM750-TMX2 Specications

2) Connector Speci󰘰cations
