7-24
.
Plug a flash drive into the 2900 Series’ USB port, then touch the [Export] button to send the selected sample results from
memory to the flash drive.
When you have finished exporting data, touch the [X] button to return to the Main screen.
A folder named YSI\BiochemistryAnalyzer will be created on the flash drive. Sample data files are copied to the Data
subfolder. The data file name will contain the instrument’s Machine ID along with the date and time.
Example Sample Data File:
7.3.2 Monitor
Touch the Monitor tab to display the list of monitor sessions.
Local Completion Time
Plate Name
Batch Name
Well Id
Chemistry
Probe Id
Concentration
Units
Endpoint (s)
Sample Size (µl)
Initial Baseline (nA)
Plateau (nA)
Final Baseline (nA)
Net Plateau (nA)
Net Plateau Temp Adj (nA)
Cross Net Plateau (nA)
Cross Net Plateau Temp Adj (nA)
Plateau Slope (nA/min)
Temperature (C)
Errors
9/10/2019 9:25 R8-0 TestBatch-2 R8_A02 Fructose 1A 24.3426 g/L 45 25 0.0179 111.713 1.7462 111.6951
111.8945 0.0166 0.0167 32.9441 27.16
9/10/2019 9:29 R8-0 TestBatch-1 R8_B01 Fructose 1A 66.503 g/L 45 25 1.4373 306.4251 5.9046 304.9878 305.7901
0.4009 0.404 84.2369 27.13
6/13/2019 9:16 Station2 MANUAL Station2 Glucose 2A 2.7406 g/L 30 25 2.6168 19.4779 2.7886 16.8611 16.9442 2.0996 24.85
6/13/2019 9:16 Station2 MANUAL Station2 Lactate 2B 2015.662 mg/L 30 25 0.2625 89.8054 1.8639 89.5428 89.5555 9.2697 24.79
6/12/2019 9:12 P96-1 REACTOR 12 P96_A01 Glutamate 3A 1.4392 g/L 30 20 0.5216 31.3612 0.8917 30.8396 31.1207 0.2681 24.55
6/12/2019 9:12 P96-1 REACTOR 12 P96_A01 Glutamaine 3B 0.1087 g/L 30 20 2.2705 32.3041 2.2708 30.0336 30.3804 30.83.4 31.121 -0.0221 24.55
