INSTALLATION
.
.
Pre-installation precautions
Please confirm that the installation personnel are qualified in relevant installation service. If the air
conditioner was installed by persons without special skills, normal operations would not be ensured, even
the personal and estate safety would be affected.
The air conditioner should be installed securely; otherwise poor installation may lead to abnormal noises and
vibration.
Outdoor unit should be installed at a spot ensuring that its air outlet noises and hot exhaust will not violate your
neighbors.
The user's installation site should be provided with regular power supply in conformity with that indicated in
nameplate of the air conditioner, and its voltage should be within a range 90 % 110 % of the rated voltage
value.
Power circuit should be equipped with protector, such as electricity leakage protector or air switch, which
should possess a capacity greater than 1.5 times the maximum current value of the air conditioner.
Never fail to adopt personal circuit and effectively-grounded socket compatible with the attached plug of the
air conditioner. The attached plug is equipped with grounding pin, and it must not be modified as desired.
Please adopt the fuse or circuit breaker prescribed in Installation Instructions.
Only qualified electrician is allowed to carry out wiring tasks strictly according to electric safety requirements.
Do ensure good earth of air conditioner, in other words, the main power switch of air conditioner must be
connected to reliable ground wire.
.
.
.
.
.
.
Please refer to the following for the center distance between the bolts
M 10 whorl is used
Please consult professional for your specific ceiling arrangement.
1.
2.
3.
Installation of the hanging screw bolt
After the main body hanging is finished, arrangement of pipe and line will be done in the ceiling.
The direction of the pipe is determined after the installation location is chosen.If the ceiling has existed,
please arrange the refrigerant pipe, drainage pipe, indoor and outdoor connecting line.
Please confirm the indoor unit dimension according to the picture below
M10 whorl is to be installed.(4 sets)
Dismantle scale of the ceiling......please keep ceiling its level. Strengthen the beam to avoid vibration.
Break the beam of the ceiling
Strengthen the breaking point of the ceiling and reinforce the ceiling beam.
User guideline
Precautions
Unit body installation
18
