1
2
3
4
5
6
7
8
12
11
10
Outdoor Unit
9
10
12
11
7
8
9
Indoor Unit
2
6
3
1
4
5
The air conditioner cannot be started up until it is powered on for 2 hours.
Furthermore, in case of a shutdown lasting for about one diel only, please do not cut
off the electricity supply. (it is necessary to heat the crankcase heater so as to avoid
force start of compressor. )
Notice that the air inlet/outlet must not be choked up. If chokeup takes place, the
air conditioner behavior may be affected, or air conditioner cannot run because of
actuation of protector.
Requirements
PARTS AND FUNCTIONS
30
1
2
3
Ambient temp
Auto temp.
＜ ℃
20
23
℃
23
℃
＞ ℃
26
20 ~
℃ ℃
26
Operation mode
HEATING ( FOR HEAT PUMP TYPE)
DRY
COOL
18
℃
FAN (FOR COOL ONLY TYPE)
FEEL MODE
SLEEP MODE
To activate the FEEL (automatic) mode of operation, press the MODE button
on the remote control until the symbol appears in the display.
In the FEEL mode the fan speed and the temperature are set automatically
according to the room temperature (tested by the probe which is incorporated in
the indoor unit)to ensure user comfort.
To optimize the working of the conditioner, adjust the temperature(only 2
)(1), the speed (2) and the direction of the air flow (3) by pressing the buttons
indicated .
± ℃
To activate the SLEEP mode of operation, press the SLEEP button on the
remote control until the symbol (AUTOQUIET ) appears in the display.
The function SLEEP automatically adjusts the temperature to make the
room more comfortable during the night sleep . In cooling or dry mode , the set
temperature will automatically raise by1 every 60 minutes, to achieve a total
rise of 2 during the first 2 hours of work.
In heating mode the set temperature is gradually decreased by 2 during the
first 2 hours of work.
After 10 hours running in sleep mode the air conditioner is swicthed off
automatically.
“ ”
℃
℃
℃
DRY MODE
This function reduces the humidity of the air to make the room more
comfortable.
To set the DRY mode , Press MODE untill appears in the display . An
automatic function of alternating cooling cycles and air fan is activated.
3
