Instrument operation

46

Screen tab bar

When each symbol is selected, the watercraft

information, function settings, and other in-

formation are shown in the center display.

(See page 47 for information on each screen.)

Center display

The center display shows the watercraft in-

formation, function settings, and other infor-

mation according to the symbol on the

screen tab bar that is selected.

Warning bar

The warning bar is shown when an error or

malfunction is detected.

Push the “OK” button of the touchpad control

when the warning symbol is displayed to

show the warning description, error code,

and other information in the center display.

(See page 50 for information about the warn-

ing descriptions.)

Trim setting indicator

The position of this indicator indicates the

trim setting of the jet thrust nozzle. (See page

32 for information on the trim setting.)

Voltmeter

The voltmeter shows the battery voltage.

When the battery voltage is normal, the volt-

meter displays approximately 14 volts.

If the battery voltage has dropped or risen

significantly, the battery voltage warning will

activate and the voltage display will blink.

(See page 51 for information on the battery

voltage warning.)

Tachometer

The tachometer shows the engine speed us-

ing the numbers ×1000 RPM (r/min) and the

number of display segments.

1 Screen tab bar

2 Center display

1 Warning bar

14.3v

RPM

x1000

km/h

2

1

1 Trim setting indicator

2 Fuel level meter

3 Voltmeter

4 Tachometer

5 Shift indicator

14.3v

RPM

x1000

km/h

1

3 4

2

5

UF5S70E0.book Page 46 Friday, October 11, 2024 9:51 AM
