Watercraft operation

32

JETBLASTER DLX

JETBLASTER LTD

TIP

If the RiDE lever is squeezed continuously,

the reverse gate will move to the reverse po-

sition.

EJU47860

Electric trim system (JETBLASTER

LTD)

The electric trim system is a function for

changing the vertical angle of the jet thrust

nozzle to change the trim angle and perfor-

mance characteristics of the watercraft.

This function can be used only for forward

operation of the watercraft.

TIP

 When the watercraft is moving in reverse or

is in neutral, the jet thrust nozzle will auto-

matically change to the neutral trim setting.

When the watercraft is shifted into forward,

the jet thrust nozzle will automatically

change to the selected trim setting.

 While the watercraft is in neutral, the

“TRIM/T.D.E.” switch controls the forward

and reverse operation of the T.D.E. (thrust

direction enhancer). (See page 34 for infor-

mation on the T.D.E.)

 The watercraft performance characteristics

according to the trim angle change de-

pending on the operating conditions.

Confirming the trim setting

The trim setting can be confirmed by the trim

setting indicator on the multifunction infor-

mation center.

To change the trim setting:

(1) Shift into forward.

(2) Push the upper side of the “TRIM/T.D.E.”

switch to increase the trim setting and

raise the bow, or push the lower side of

the “TRIM/T.D.E.” switch to decrease the

trim setting and lower the bow. The trim

angle can be adjusted in the range of the

trim settings –2 to +2.

1 “N” (Neutral position)

1

14.3v

RPM

x1000

km/h

1

1 Trim setting indicator

14.3v

RPM

x 1000

km/h

1
