Instrument operation

42

Screen tab bar

When each symbol is selected, the watercraft

information, function settings, and other in-

formation are shown in the center display.

(See page 43 for information on each screen.)

Center display

The center display shows the watercraft in-

formation, function settings, and other infor-

mation according to the symbol on the

screen tab bar that is selected.

Warning bar

The warning bar is shown when an error or

malfunction is detected.

Push the “OK” button of the touchpad control

when the warning symbol is displayed to

show the warning description, error code,

and other information in the center display.

(See page 49 for information about the warn-

ing descriptions.)

Trim setting indicator

The position of this indicator indicates the

trim setting of the jet thrust nozzle. (See page

31 for information on the trim setting.)

Voltmeter

The voltmeter shows the battery voltage.

If the battery voltage has dropped or risen

significantly, the battery voltage warning will

activate and the voltage display will blink.

(See page 49 for information on the battery

voltage warning.)

Tachometer

The tachometer shows the engine speed and

the number of display segments.

Shift indicator

This indicator shows the reverse gate shift

positions: “F” (forward), “N” (neutral), and “R”

(reverse). (See page 29 for shifting proce-

dures.)

Fuel level meter

The fuel level meter shows the amount of fuel

remaining in the fuel tank using the number of

display segments.

If the amount of remaining fuel is low, the fuel

level warning will activate. (See page 49 for

information on the fuel level warning.)

1 Warning bar

1

1 Trim setting indicator

2 Fuel level meter

3 Voltmeter

4 Tachometer

5 Shift indicator

1

3 4

2

5

UF4P76E0.book Page 42 Thursday, June 13, 2024 3:38 PM
