Specifications

117

EJU46451

Specifications

Watercraft capaci-

ty:

Maximum people on board: 3 person

Maximum load capacity: 240 kg (530 lb)

Dimensions and

weight:

Length: 3.58 m (140.9 in)

Width: 1.27 m (50.0 in)

Height: 1.23 m (48.4 in)

Dry weight:

372 kg (820 lb) (FX HO)

379 kg (836 lb) (FX HO with audio)

380 kg (838 lb) (FX CRUISER HO)

Performance: Maximum output (according to ISO

8665/SAE J1228):

143.4 kW at 7600 r/min

Maximum fuel consumption:

59.6 L/h (15.7 US gal/h,

13.1 Imp.gal/h)

Cruising range at full throttle: 1.17 hour

Trolling speed: 1500 ±100 r/min

Engine: Engine type: Liquid cooled 4-stroke, DOHC

Number of cylinders: 4

Engine displacement: 1898 cm³

Bore × stroke: 88.0 × 78.0 mm (3.46 × 3.07 in)

Compression ratio: 11.2 : 1

Valve clearance-intake (cold): 0.14–0.23 mm (0.0055–0.0091 in)

Valve clearance-exhaust (cold): 0.28–0.37 mm (0.0110–0.0146 in)

Lubrication system: Wet sump

Cooling system: Water

Starting system: Electric

Ignition system: T.C.I.

Spark plug (NGK): LFR6A

Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)

Battery capacity: 12 V, 18 Ah

Battery type: YTX20L-BS

Charging system: Flywheel magneto

Drive unit: Propulsion system: Jet pump

Jet pump type: Axial flow, single stage

Impeller rotation: Counterclockwise

Jet thrust nozzle angle: 24+24 °

Jet thrust nozzle trim angle: -5, -3, 0, 3, 6 °

UF7K71E0.book Page 117 Friday, July 5, 2024 2:49 PM
