SB168-ES Owner’s Manual
20
Troubleshooting
Troubleshooting
Symptom Possible Solution
The power won’t turn on. The power indicator
doesn’t light.
• Is the power cable connected properly? (page 6)
• Is the [POWER] switch properly engaged? (page 7)
• If you’ve checked all possible causes and the power still won’t come on, refer the
problem to your Yamaha dealer.
The unit is not receiving an input signal. • Are the input cables properly connected?
• Are the source devices delivering an appropriate signal? Check the SIG indicators
on the appropriate channels.
•Have you executed the Quick Setup function? Did you change any patch settings via
the AVS-ESMonitor application after executing the Quick Setup function?
• Are the AVS-ESMonitor patch settings appropriate (Net Patch or I/O Patch page)?
• Is the head amplifier gain set to an appropriate level?
The input level is too low. • If a condenser microphone is being used, is the [+48V MASTER] switch ON?
• If a condenser microphone is being used, is phantom power for the corresponding
channel(s) turned ON?
• Is the head amplifier gain set to an appropriate level?
No output. • Are the output cables properly connected?
•Have you executed the Quick Setup function? Did you change any patch settings via
the AVS-ESMonitor application after executing the Quick Setup function?
• Are the AVS-ESMonitor patch settings appropriate (Net Patch or I/O Patch page)?
• Is output muted at the digital mixing console?
An error message is displayed during Quick
Setup.
• Refer to page 17 for information on error messages that might be displayed during
execution of the AVS-ESMonitor Quick Setup function.
Head amplifier remote control isn’t working. • Did you make the appropriate Head Amp Controller setting when executing the
Quick Setup function? Did you change the Serial Communication Mode setting after
executing the Quick Setup function?
• Is the AVS-ESMonitor Serial Communication Mode set properly? (page 16)
• If you will be controlling the head amplifiers via the 9-pin D-sub REMOTE connector
on a digital mixing console, is the mixing console’s REMOTE connector properly
connected to the HA REMOTE connector on the MY16-ES64 card (Primary Mas-
ter)? (page 14)
• If you will be controlling the head amplifiers via a mixing console expansion slot, is
the EXTERNAL HA display COMM PORT parameter set appropriately? (page 14)
• Set up the digital mixing console input patching in sequential 8-channel groups for
the slot inputs (CH1–8, CH9–16, etc.). This makes it easy to select input channels
on the external SB168-ES units for remote head amplifier control.
Can’t control the SB168-ES by the M7CL-
48ES.
• Is the Stage Box Setup function of the M7CL-48ES set properly?
• Did you correctly set the DIP switches before turning on the power to the devices?
• Has the firmware been updated to an appropriate version?
• Can’t execute Quick Setup in the AVS-
ESMonitor
• Can’t change Serial Communication Mode
in the AVS-ESMonitor
• Is the AUTO CONFIGURE button for the Stage Box Setup function turned off?
• Are DIP switches 5–8 for the SB168-ES set to OFF (upper position)?
