Operations From the External Device
Rio3224-D3 Rio1608-D3 Reference Manual
34
Turning Remote Only On/Off
The Remote Only function disables parameter editing from the front panel of the Rio-D3 to
prevent unintentional changes to parameter values.
This function is always off when the Rio-D3 starts up.
NOTE
• You can still edit the SETUP menu items (SETUP and CONTROL) even when Remote Only is
On.
• You can still adjust parameters from a supported device even when Remote Only is On.
To turn it On
Set it to On from the supported device when the device and the Rio-D3 are synchronized.
Even if the connection to the supported device is lost while the Remote Only function is On,
the function will remain turned On.
When Remote Only is On, the REMOTE ONLY icon appears on the home screen of the Rio-
D3 display.
To turn it Off
Disable the function from the supported device, or turn the power to the Rio-D3 off and then
on again.
When Remote Only is turned Off, the REMOTE ONLY icon disappears.
Control from an External Device
Connecting the Rio-D3 to a supported device enables you to control the Rio-D3 remotely. The
display of the supported device that is connected to the Rio-D3 indicates the model name and
UNIT ID of the Rio-D3.
For information on connecting a supported device to the Rio-D3, and monitoring and
controlling the unit from the device, please refer to the owner’s manual for the corresponding
supported device.
Parameters that you can monitor and control
“*” (asterisk) indicates a parameter that applies to With Recall. The With Recall function
applies the HA parameters stored in the mixing console to the Rio-D3 when a scene is
recalled on the console.
REMOTE ONLY icon
Parameter Description
HA Gain* You can adjust the gain in the range of –6 dB to +66 dB in 1 dB
units.
+48V ON/OFF* Turns +48V phantom power ON or OFF for each channel.
HPF ON/OFF* Turns the high pass filter ON or OFF.
HPF Cutoff Frequency* Adjusts the cutoff frequency of the high pass filter (12 dB/Oct.) in
the range of 20 Hz to 600 Hz in 60 steps.
GC ON/OFF* Turns the Gain Compensation ON or OFF.
OUTPUT Gain Specifies the OUTPUT gain.
OUTPUT PHS (Phase) ON/OFF Turns OUTPUT Phase on/off.
OUTPUT DLY (Delay) ON/OFF Turns OUTPUT Delay on/off.
OUTPUT Delay Specifies the OUTPUT Delay value.
REMOTE ONLY ON/OFF Turns Remote Only on/off.
+48V ACTIVE Indicates the on/off status of +48V phantom power supply.
Analog input level meter Indicates a level meter for each analog input channel.
Analog output level meter Indicates a level meter for each analog output channel.
Digital output level meter Indicates a level meter for each digital output channel.
Firmware version Indicates the firmware version.
Device Identify command Identifies the target Rio-D3 unit among multiple devices in a
Network.
Port Identify command Identifies the target I/O port among multiple devices in a Network.
[SYSTEM]/[SYNC] status
indication and messages
Notifications of status information via [SYSTEM]/[SYNC]
indicators and messages.
