Screens
Rio3224-D3 Rio1608-D3 Reference Manual
22
DANTE menu
This menu displays information for Dante-related settings.
While the DANTE screen is displayed, turn the encoder with switch to select a parameter.
The screen displays the following items. You cannot modify these settings on the Rio-D3.
Item Description
DANTE NAME Indicates the Dante device label.
The device label can be specified from Dante Controller. Follow the
instructions below:
• Do not modify the first five characters, which are Y0##- (“##” represents the
UNIT ID). Even if you try to change these characters, they will automatically
be corrected to Y0##-.
• You can use up to 31 characters total.
S.RATE
(SAMPLE RATE)
Indicates the sampling frequency (Fs) and Pull-Up/Down status.
ENCODING Indicates the bit depth. Supports 24-bit and 32-bit.
The default value is 24-bit. You can modify the setting from Dante Controller.
LATENCY Indicates the latency value. Supports 0.25 ms, 0.5 ms, 1.0 ms, 2.0 ms, and
5.0 ms.
(If the unit belongs to a DDM domain, you can additionally select from 10 ms,
20 ms, and 40 ms.)
The default value is 1.0 ms. You can modify the setting from Dante Controller.
P. LE A DE R
(PREFERRED
LEADER)
Indicates the PREFERRED LEADER status (ON/OFF).
(If the unit belongs to a DDM domain, a “-” (hyphen) appears.)
SEC.PORT
(SECONDARY PORT)
Indicates the operating mode setting for the SECONDARY port.
PRIMARY Indicates the link status and speed, and IP address for the PRIMARY port.
SECONDARY Indicates the link status and speed, and IP address for the SECONDARY port.
DEV.LOCK Indicates the DANTE DEVICE LOCK status (ON/OFF).
AES67 MODE Indicates the AES67 MODE status (ENABLE/DISABLE).
DANTE
S.RATE ENCODING LATENCY P.LEADER
PRIMARYSECONDARY
AES67
MODE
DANTE
NAME
DDM
STATE
DEV.
LOCK
SEC.
PORT
DDM STATE Indicates whether the unit belongs to a DDM domain, and the status of
Controller Permissions.
• - (no DDM connection)
• READ/WRITE
• READ ONLY
• DISCONNECT (when the unit belongs to a DDM domain, but is not
connected to DDM)
Item Description
