DME8i-ES/DME8o-ES/DME4io-ES Owner’s Manual
39
General Specifications
Electrical Characteristics
Output impedance of signal generator: 150 Ω
DME8i-ES : Measured with DME8o-ES
DME8o-ES : Measured with DME8i-ES
DME4io-ES: Measured with DME4io-ES
Frequency Response fs=48kHz@20Hz–20kHz, reference to the nominal output level @1kHz
fs=96kHz@20Hz–40kHz, reference to the nominal output level @1kHz
<DME8i-ES>
<DME8o-ES>
<DME4io-ES>
Gain Error @1kHz
<DME8i-ES>
Sampling Frequency
External Clock
Normal Rate: 44.1/48 kHz (±0.1%)
Double Rate: 88.2/96 kHz (±0.1%)
Internal Clock
Normal Rate: 48 kHz (±50ppm)
Double Rate: 96 kHz (±50ppm)
Maximum Voltage Gain
Gain: –60dB, RL:600Ω, 64dB INPUT to OUTPUT
Miscellaneous
Power Consumption 40W
Dimensions (HxDxW) 44x361x480 mm
Net Weight 4.5kg
Temperature range
operating: 5 to 40˚C
storage: –20 to 60˚C
Include Accessories
AC Power cord, Mini Euro plug(16P)x1, Euro plug(3P)x8, Owner’s Manual,
Rubber feetx4
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600Ω
input level: –60dBu, GAIN: –60dB –1.5 0.0 +0.5 dB
input level: +10dBu, GAIN: +10dB –1.5 0.0 +0.5 dB
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600Ω input level: +10dBu, GAIN: +10dB –1.5 0.0 +0.5 dB
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–4 OUTPUT 1–4 600Ω
input level: –60dBu, GAIN: –60dB –1.5 0.0 +0.5 dB
input level: +10dBu, GAIN: +10dB –1.5 0.0 +0.5 dB
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600Ω
input level: –60dBu, GAIN: –60dB
→ output level: +4.0dBu (typ.)
–2.0 0 +2.0 dB
input level: +10dBu, GAIN: +10dB
→ output level: +4.0dBu (typ.)
–2.0 0 +2.0 dB
