DME8i-ES/DME8o-ES/DME4io-ES Owner’s Manual
41
Hum&Noise fs=48kHz or 96kHz, EIN=Equivalent Input Noise
<DME8i-ES>
<DME8o-ES>
<DME4io-ES>
Dynamic Range fs=48kHz or 96kHz
<DME8i-ES/DME8o-ES>
<DME4io-ES>
Crosstalk@1kHz reference to the level of output N
<DME8i-ES/DME8o-ES>
<DME4io-ES>
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600Ω
Rs=150Ω, GAIN: –60dB
All input & output level controls: 0dB
–128
EIN
–127
EIN
dBu
–64 dBu
Rs=150Ω, GAIN: +10dB
All input & output level controls: 0dB
–82 –79 dBu
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600Ω
Rs=150Ω, GAIN: +10dB
All input & output level controls: 0dB
–82 –79 dBu
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–4 OUTPUT 1–4 600Ω
Rs=150Ω, GAIN: –60dB
All input & output level controls: 0dB
–128
EIN
–127
EIN
dBu
–64 dBu
Rs=150Ω, GAIN: +10dB
All input & output level controls: 0dB
–82 –79 dBu
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz; equivalent to a 20kHz filter with infinite dB/octave
attenuation.
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600Ω GAIN: +10dB 106 dB
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–4 OUTPUT 1–4 600Ω GAIN: +10dB 106 dB
* Dynamic range are measured with a 6dB/octave filter @12.7kHz; equivalent to a 20kHz filter with infinite dB/octave
attenuation.
from to CONDITIONS MIN TYP MAX UNITS
INPUT N OUTPUT (N–1) or (N+1) N = 1–8, GAIN: +10dB –80 dB
from to CONDITIONS MIN TYP MAX UNITS
INPUT N OUTPUT (N–1) or (N+1) N = 1–4, GAIN: +10dB –80 dB
*Crosstalk is measured with a 18dB/octave filter @80kHz
