CTL-BN1 Reference Manual
5
Introduction
Included items
• Owner’s Manual
• Safety Guide
* An Ethernet cable and wall mounting screws are not included.
Items to prepare
• PSE (power sourcing equipment) compliant with IEEE802.3at (PoE+) or IEEE802.3af (PoE)
Used between this unit and a Dante device, such as RM-CR, in order to supply power to this unit. In an ADECIA
solution, network switch SWR2311P-10G can be used as a PSE.
* PSE (power sourcing equipment): Generic term for PoE injector and PoE network switch
• Ethernet cable
Used between the following devices.
- Dante device and PSE
- PSE and this unit
A Controller B Wall mounting
plate
C Wall mounting
cover
D Mounting screw E Button label
×
1 × 1 × 1 × 2 × 1
NOTE
• Prepare a CAT5e or higher Ethernet cable that complies with the IEEE802.3at standard.
• Cables up to a maximum length of 100 m can be used.
• In order to prevent electromagnetic interference, use STP (shielded twisted pair) cables.
M3 × 8 mm
