5
Verify Measurements with the Check Your Door Guide
Equals I
Less than I
(Adjust diameter
to 1")
Greater than I
(Your door is not
a match for a
Yale smart lock)
X
1"
(25mm)
Dia.
1" (25mm) Dia.
1" (25mm) Deep
Frame
Equals I
Less than I
(Adjust diameter
and depth to 1")
Greater than I
(Your door is not
a match for a
Yale smart lock)
X
X
2- /8" ( mm)154
OR
1-1/2" (38mm)
Equals G or H
Less than G
(Adjust diameter
to G or H)
Greater than H
(Your door is not
a match for a
Yale smart lock)
X
X
MeasureStrike Pocket
Diameter and Depth
Measure Cross Bore
Greater than A
Less than A
(Your door is
not a match for
aYale smart
lock)
X
Measure Clearance
B, C, or D
Less than B
(Your door is not
a match for a
Yale smart lock)
Greater than D
(Your door is not
a match for a
Yale smart lock)
X
Measure Door Thickness
X
2- /8" ( mm)360
or
2-3/4" (70mm)
Backset
Equals E or F
Less than E or F
(Your door is not
a match for aYale
smart lock)
Greater than E or F
(Your door is not
a match for aYale
smart lock)
X
X
Measure Backset
Measure Face Bore
Recommended Location
of DoorSense
X
A: Within
2" of Yale
logo on
battery
cover.
G: Within
1-1/2" from
inside
frame
edge.
"2
51(mm)
"1-1/2
38(mm)
Cut Here
