VR-5000 OPERATING MANUAL 51
2. Select the monitoring memory channel (“
DVR ch1DVR ch1
DVR ch1DVR ch1
DVR ch1” or “
DVR ch2DVR ch2
DVR ch2DVR ch2
DVR ch2”) by pressing the
[
MODE
(
ADRS
)]
key.
3. Press the
[
F
]
key momentarily, then press the
[
STEP
(
PLAY
)]
key to start the monitor.
Notes:
• If you select the “
DVR ch1DVR ch1
DVR ch1DVR ch1
DVR ch1” channel for playback, it will play back audio for 16 seconds
(irrespective of the actual recording time).
• If you select the “
DVR ch2DVR ch2
DVR ch2DVR ch2
DVR ch2” channel for playback, it will play back audio for 8 seconds
(irrespective of the actual recording time).
FIELD STRENGTH METER
The VR-5000 can provide display of the relative receiving signal strength on the LCD,
compared to some user-defined “baseline” field strength.
1. Press the
[
F
]
key momentarily, then press the
[
4
(
SPL
)]
key.
2. Rotate the DIAL knob to set the cursor to the “
BASE FIELD STRENGTHBASE FIELD STRENGTH
BASE FIELD STRENGTHBASE FIELD STRENGTH
BASE FIELD STRENGTH” menu option,
then press the
[
ENT
(
SET
)]
key.
3. You will now observe the display of the cur-
rent signal strength (“
CURRENTCURRENT
CURRENTCURRENT
CURRENT” row) and its
peak level (“
REFERENCEREFERENCE
REFERENCEREFERENCE
REFERENCE” row). The first time
this is done, these levels will be the same (al-
though the “
CURRENTCURRENT
CURRENTCURRENT
CURRENT” level will appear to
have a very slightly lower value, due to the
“damping” in the metering).
4. If you are resetting the reference level, press the
[
0
(
NB
)]
key to equalize the peak level
to the current signal strength.
5. To cancel the Field Strength Meter displays the
[
ENT
(
SET
)]
key momentarily; this
will save the peak level and let you exit to the menu mode.
6. Confirm that the cursor is on the “
CANCELCANCEL
CANCELCANCEL
CANCEL” menu selection, then press the
[
ENT
(
SET
)]
key to exit to normal operation.
If you want to display the current signal level (for example, on a different channel), com-
pared to the reference level, use the following process:
1. Press the
[
F
]
key momentarily, then press the
[
4
(
SPL
)]
key.
2. Rotate the DIAL knob to set the cursor to the “
CURRENT FIELD STR.CURRENT FIELD STR.
CURRENT FIELD STR.CURRENT FIELD STR.
CURRENT FIELD STR.” menu option,
then press the
[
ENT
(
SET
)]
key.
3. The current signal strength (“
CURRENTCURRENT
CURRENTCURRENT
CURRENT” row) and the memorized peak level (“
REF-REF-
REF-REF-
REF-
ERENCEERENCE
ERENCEERENCE
ERENCE” row) will be displayed.
4. To cancel the Field Strength Meter display, press the
[
ENT
(
SET
)]
key momentarily, to
save the peak level and exit to menu mode.
5. Confirm that the cursor is on the “
CANCELCANCEL
CANCELCANCEL
CANCEL” menu, then press the
[
ENT
(
SET
)]
key to
exit to the normal operation.
Miscellaneous Features
