87
Specifications
General
Frequency Range: TX: 118.000 to 136.975 MHz
RX: 108.000 to 136.975 MHz (NAV and COM bands)
161.650 to 163.275 MHz (Weather Channels; USA/Canada only)
329.150 to 335.000 MHz (Glide slope; FTA-750L only)
Channel Spacing: 25 kHz/8.33 kHz
Emission Type: TX: AM
RX: AM & FM (FM: for receiving the Weather Channels)
Supply Voltage: 6.0 to 9.5 VDC
Current Consumption (approx.): 300 µA (power o),
70 mA (battery saver on, saver ratio 50%)
80 mA (squelch on),
300 mA (receive),
0.9 A (transmit 1.5 W Carrier)
Temperature Range: +14 ºF to + 140 ºF (–10 ºC to +60 ºC)
Case Size (W x H x D): 2.4 x 5.2 x 1.3 inches (62 x 133 x 34 mm) with SBR-39LI
Weight (approx.): 14.5 oz (410 g) with SBR-39LI, antenna and belt clip
Receiver
Circuit Type: Double-conversion superheterodyne
IFs: 47.25 MHz & 450 kHz
Sensitivity: Better than 0.8 µV (for 6 dB S/N with 1 kHz, 30 % modulation)
Selectivity: >8 kHz/–6 dB
Adjacent CH. Selectivity: <25 kHz/–60 dB
AF Output (@7.4 V): 0.8 W @ 16 Ohms, 10 % THD
