2
FT-847 OPERATING MANUAL
GENERAL
Frequency Range: Receive 100 kHz - 36.99 MHz
37 - 76 MHz
108 - 174 MHz
420 - 512 MHz
Transmit 160 - 6 Meters
2 Meters
70 Centimeters
(Amateur bands only)
5.1675 MHz (Alaska Emergency Channel)
Emission Modes: USB, LSB, CW, AM, FM, F1 (9600 bps Packet), F2 (1200 bps Packet), AFSK
Synthesizer Steps (Min.): 0.1 Hz (CW/SSB)
10 Hz (AM/FM)
Antenna Impedance: 50Ω, Unbalanced
Operating Temp. Range: −10ºC to +50ºC (14ºF to 122ºF)
Frequency Stability: Better than ±2 ppm (0ºC to +40ºC) SSB/CW/AM/AFSK
Better than ±5 ppm (−10ºC to +50ºC) SSB/CW/AM/AFSK
Better than ±{1 kHz ±5 ppm} FM
Power Requirements: DC 13.8V
—
---
±10%, Negative Ground
Current Consumption: Receive (Squelched): 1.5A
Receive (Max. Audio): 2.0A
Transmit: 22A (@ 100W RF output)
Case Size: 260(W) x 86(H) x 270(D) mm (10.24” x 3.39” x 10.63”)
Weight: Approximately 7 kg (14.4 lbs.)
TRANSMITTER
Power Output: 160 - 6m: 100 Watts (25 Watts AM carrier)
2m/70cm: 50 Watts (12.5 Watts AM carrier)
Modulation Types: SSB: Balanced Modulator
FM: Variable Reactance
AM: Early Stage (Low Level)
FM Maximum Deviation: ±5 kHz (±2.5 kHz on FM-N)
Spurious Radiation: Harmonics: At least 40 dB down (1.8 - 29.7 MHz)
At least 60 dB down (50/144/430 MHz)
Non-harmonic: At least 50 dB down (1.8 - 29.7 MHz)
At least 60 dB down (50/144/430 MHz)
Carrier Suppression: At least 40 dB
Opp. Sideband Suppression: At least 40 dB
3rd-Order IMD: At least 31 dB down (14 MHz, 100W PEP output)
SSB Frequency Response: 400 Hz - 2600 Hz (−6 dB)
Microphone Impedance: 200Ω - 10kΩ (Supplied microphone: 600Ω)
Specifications
