WIRELESS SYSTEM
1. Tuning bandwidth: 2400 – 2483.5 MHz
2. Working range: 90 ft (indoors). Actual range depends on RF signal
absorption, reection and interference.
3. Audio frequency response:
20 Hz – 20 kHz (-3dB). Dependent on microphone type or input signal.
4. Dynamic range: 108 dB
5. Signal-to-noise ratio: 108 dB
6. RF sensitivity: -88 dBm
7. Total harmonic distortion: 0.2%
8. RF output power: 10 mW E.I.R.P. max
9. Operating temperature range:
0°C to 45°C. Battery characteristics may limit this range.
10. Channel count: 6
11. Charging voltage and current: 5V / 2A
12. Charging time: 2.5 hours
13. Sample rate: 24-bit / 48 kHz
14. Latency: less than 5 ms
15. Battery life: up to 5 hours
RECEIVER
1. Dimensions: 31 mm x 29 mm x 98 mm
2. Weight: 92 g
3. Housing: Molded plastic and cast metal
4. Battery: 3.7V rechargeable Li-ion, 860 mA
5. Output impedance: 470 Ω (1 kHz)
6. Audio output connector: XLR balanced male
7. Maximum output level: 3.6 Vp-p
8. USB type: USB Type-C
9. Antenna impedance: 50 Ω
10. Antenna Type: 1/4 wave sleeve dipole, non-removable
11. Number of antennas: 2
SPECIFICATIONS
13
