GAIN: Manual
For those who are new to recording: Gain and Dierent Sources
Whenever you plug a source such as an instrument or microphone into an Input, you must
set the "GAIN Level" to suit the type of source you’re plugging in. You may have noticed that
singers, for example, can have very dierent dynamics from singer to singer. Some modern
singers barely whisper into the microphone, and others scream very loud! This is exactly
why we must set a Gain Level for each input that matches the type of source. If Gain is not
set properly, you will get distortion from overloading the input if it is set too high.
Preamp Settings
• Gain – 60 dB of gain in 1 dB increments – this is an analog preamp that is digitally
controlled. Use the lower encoder to manually set the preamp gain of the selected
channel.
o Auto Gain make sure to see the next page for Auto Gain info.
• In addition to manual GAIN, the buttons to the left of the screen are selectable
PER CHANNEL and oer many useful preamp controls:
o 48V – Phantom Power – clicking this on to apply to a channel will power
condenser mics and active direct boxes.
o Phase – you can ip the PHASE on any channel by 180 degrees. This is often
helpful when recording a source with multiple microphones such as drums.
o Hi-Pass Filter – this is used on some sources to cut the frequences below
100 Hz. It can clean up microphones that do not need lower frequencies.
o INST – If you’re plugging an instrument into one the front combo jacks you
can set this to INST. For highest quality, you many want to consider using a DI
box and just apply GAIN as normal.
o DIRECT – this is an advanced setting that is described in detail on page
“POST-DAW Plugin Monitoring.” Basically, this allows you to turn the DIRECT
monitoring on/o, on a per-channel basis. It allows you to use plugins in your
DAW–such as Amp Simulators for guitar or bass, or “Auto-Tune” plugins for
vocals–and then choose whether you hear the eected signal (DIRECT o) or
your input signal without the eect applied (DIRECT on).
