18

2×20V cordless lawn

scarier/aerator 2 in 1

EN

3. Scarier/Aerator runs

but not working properly

or performance is

unsatisfactory.

A. Has battery been fully charged? Plug in charger and wait for green light to come on.”

B. Release Operating Bail to turn scarier/aerator off. Remove batteries. Turn scarier/

aerator over and check:

-Tine cylinder and blade cylinder for sharpness - Replace tine cylinder or blade cylinder

as needed if tine cylinder or blade cylinder is worn or damaged.

-Deck and discharge chute for clogging.

C. Operating height is not appropriate.Adjust the height.

4.Scarier/Aerator is too

hard to push.

A. Raise height to reduce deck drag on grass. Check each wheel for free rotation.

B. Check whether grass is wrapped on tine cylinder or blade cylinder, if so, release

Operating Bail to turn scarier/aerator off and remove battery packs, then

remove the grass. It is suggested to check whether grass is wrapped on tine

cylinder or blade cylinder and remove excess grass before operation.(See Fig.L)

5.Scarier/Aerator is

abnormally noisy and

vibrates.

A. Release Operating Bail to turn scarier/aerator off. Remove batteries. Turn

scarier/aerator on side and check tine cylinder or blade cylinder to ensure it has

not been bent or damaged. If tine cylinder or blade cylinder are damaged, replace

with replacement tine cylinder or blade cylinder. If the underside of the deck is

damaged return scarier/aerator to an Authorized service center.

6. Battery charger LED’s

not on.

A. Check plug connection.

B. Replace charger.

7. Battery charger LED

does not ip to green.

A. Battery needs to be diagnosed. Take to authorized service center.

8. Scarier/Aerator

not picking up grass

clippings with the Grass

Collection Bag.

A. Chute clogged. Release Operating Bail to turn scarier/aerator off. Remove

batteries. Clear chute of grass clippings.

B. Bag full. Empty bag more often.

9. Low or diminished

run-time after many

uses

A. Return to Authorized Service location - may need new battery.

10. The battery charger

LED ashes red and

the battery can’t be

charged.

A. The battery overheats after continuous use. Remove battery from the charger

and allow it to cool to 42°C or less.

FOR BATTERY TOOLS

The ambient temperature range for the use and storage of tool and battery is 0°C-45°C.

The recommended ambient temperature range for the charging system during charging is 0°C-40°C.
