Operating Instructions Operating Instructions

PROBLEM CAUSE REMEDY

The unit does not

start when pressing

Not plugged in / Plug or socket is damaged. Plug in or replace the power or socket.

A fuse is blown or broken. Replace the fuse (3.15A/250AC).

The room temperature is lower than the set temperature.

(Cooling mode)

Reset the temperature.

Not cool enough

The doors or windows are not closed. Make sure all the windows and doors are closed.

There are heat sources inside the room. Remove the heat sources if possible.

The exhaust air hose is not connected or blocked. Connect or clean the exhaust air hose.

Temperatu

re setting is too high. Reset the temperature.

The air inlet is blocked. Clean the air inlet.

High noise level

air conditioner

It is normal.

If you are having trouble with your portable air conditioner, please refer to troubleshooting section below.

If nothing of the below works, please contact your retailer for servicing of your Air Conditioner.

Error Codes CAUSE REMEDY

E2 Code

Room temperature sensor failed or is damaged. Replace room temperature sensor.

E3 Code

Evaporator temperature sensor failed. Replace evaporator temperature sensor.

E4 Code

Water tank full. Please empty the water tank.

*This marking indicates that this product should not be disposed of with other household wastes throughout the EU. To prevent possible

harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of

material resources. To return your us device, please use the return and collection systems or contact the retailer where the product was

purchased. They can take this product for environmentally safe recycling.

*Used batteries must not be disposed of through household garbage,since they might contain toxic elements and heavy metals that can be

harmful to the environment and human health. Return empty batteries to an appropr

iate recycling facility.

NOTE!

and read about how to get

extended warranty. Please visit

www.woods.se for more information.

Recommended limits for use

The best operating ambient temperature

for cooling is 17-35 °C,

Fuse Parameter: φ5.0x20mm

3.15A, 250Vac.

Cooling/Heating capacity 2000 W/1500W 2600 W/2000W

Cooling/Heating Power consumption 750 W/600W 950 W/750W

Airflow: 350 m

/h 350 m

Energy class A A

Dehumidification 19 L / 24h 24 L / 24h

Temperature setting 15-31°C 15-31°C

Working temperature 16-43°C 16-43°C

EER 2,6 2,7

Length of air exhaust hose 1,5 m 1,5 m

Diameter of the air exhaust hose pipe 155mm 155mm

Refrigerant gas R290/100g R290/160g

Noise level in decibels 51dB 51dB

Weight 22.5kg 24.5kg

Dimensions in mm, L x Wx H 355x350x700 355x350x700

TECHNICAL DATA

*Technical changes and improvements may occur. All values are approximate and may vary due to external circumstances such as

temperature, ventilation, and humidity.

NOTE!

and read about how to get an extended

warranty. Please visit www.woods.se for

more information.

Guarantees

2 years consumer warranty against production faults. Please note that the warranty is only valid upon

the production of the receipt. The warranty is only valid if the product is used in accordance with

the instructions and security warnings expressed in this manual. The warranty does not cover any

damages caused by improper handling of the product.

NOTE: The 2 years warranty only applies for consumers and not to

commercial use of the unit.

WIFI Smart Home DuoC Milan 9K

WIFI Smart Home DuoC Milan 7K
