~ 74 ~
Behind the aluminium grease filter is the motor of the appliance. The carbon
filters are installed on the motor.
3. The CARBON FILTERS are intended to be installed on both sides of the motor.
4. Place the CARBON FILTER on the motor and turn it clockwise until it is firmly
tightened (s. fig. below).
Fig. similar: modifications are possible.
1
MOTOR
2
CARBON FILTER
3
CLOCKWISE ROTATION
Place the CARBON FILTER on the motor and turn the filter clockwise
until it is installed properly.
5. Repeat the procedure on the other side of the motor.
6. If you want to uninstall the CARBON FILTERS, turn the filters anti-clockwise and
remove them.
7. Reinstall the aluminium grease filter: insert the aluminium grease filter
properly into the corresponding slots on the extractor hood. Press and hold the
locking button on the grease filter handle while pushing the aluminium grease
filter into its proper position. Once the aluminium grease filter is properly in
position, release the locking button to lock the grease filter in place.
8. Close the appliance.
WARNING! Install the carbon filters safely and properly; otherwise, the
carbon filters can loosen and cause hazardous situations.
WARNING! Operate the appliance with inserted aluminium grease
filters only. Otherwise, recirculating-transported fat will deposit in the
appliance and the exhaust system. RISK OF FIRE!
NOTICE! The suction capacity is decreased by installed carbon filters.
