• If thermocouple adaptor (see TOOLS) is
available,
check closed circuit voltage as outlined
in the test procedure.
• If thermocouple adaptor is not available, check
open circuit voltage as outlined in the test
procedure.
• If a VOM is not available, replace the
thermocouple with a new one as outlined under
the appropriate procedure below and check
operation. Refer to
STANDARD OVEN PILOT
ASSEMBLY AND THERMOCOUPLE
1. Disconnect
thermocouple from gas safety valve.
2. Select the test to perform.
3. Closed Circuit.
A. Install thermocouple adaptor at the
threaded connection on gas safety valve.
B. Install thermocouple to the adaptor.
Do not overtighten the thermocouple nut or the
insulator could be crushed, shorting the
thermocouple.
Finger tighten the nut plus 1/4 turn with
a wrench only.
C. Light the pilot. Allow pilot to heat
thermocouple for one to two minutes.
D. Connect one meter lead to the adaptor test
point and the other meter lead to the tube.
Compare reading to the value listed in the
table below.
4. Open Circuit.
A. Connect one meter lead to the tip of the
threaded end and the other meter lead to the
tube. Compare reading to the values listed
in the table below.
B. Light the pilot and continue to hold down the
pilot gas button on the safety valve during
this test. Allow pilot to heat thermocouple for
one to two minutes.
C. Compare reading to the value listed in the
table below.
THERMOCOUPLE MV READINGS
Closed Circuit Open Circuit
Range 8 to 25 MV 25 to 35 MV
5. If readings are less than the minimum stated
above, replace the thermocouple as outlined
under the appropriate procedure below and
check for proper operation.
If a VOM is not available, replace the
thermocouple with a new one as outlined under
the appropriate procedure below and check
operation.
• STANDARD OVEN PILOT ASSEMBLY
AND THERMOCOUPLE
6.
Check for proper operation.
WX RANGE - 3. SERVICE PROCEDURES, TEST AND ADJUSTMENTS
Page 19 of 27 F45992 (1123)
