vMON-Series
Page 35
c. TSL4.0: The UMD characters can be set remotely using TSL4.0
protocol using an RS422 interface, 8-bits, 1 stop bit, even parity,
38400 baud.
d. TSL5.0: The UMD characters can be set remotely using TSL5.0
protocol using the LAN interface, with the default IP address of the
monitor: 192.168.1.155.
4. UMD Character 1: The name that will appear in single screen mode or in
Win1 when in Quad Mode.
5. UMD Character 2: The name that will appear in Win2 when in Quad Mode.
6. UMD Character 3: The name that will appear in Win3 when in Quad Mode.
7. UMD Character 4: The name that will appear in Win4 when in Quad Mode.
8. UMD ID: The IMD ID address can be set anywhere from 0 to 126. When
multiple monitors are cascaded, each monitor can be set to a different
address so that they may be distinguished individually. This address is used
by the RS-422 connection when TSL3.1 or TSL4.0 protocol is used.
9. UMD Screen ID: The IMD Screen ID can be set anywhere from 0 to 65534.
This is only available when using TSL5.0 protocol.
10. UMD Display ID: The IMD Display ID can be set anywhere from 0 to
65534. This is only available when using TSL5.0 protocol.
11. Baud Rate: The RS-422 baud rate may be set to one of the following
values: 4800, 9600, 19200, 38400, 57600, or 115200. The default baud rate
is 38400.
12. LED Tally: The LED Tally may be turned ON or OFF.
13. UMD Tally Color: The UMD Tally Color may be set as follows:
a. OFF: OSD Tally is turned off.
b. RG: This selects OSD Tally RG Mode.
c. GR: This selects OSD Tally GR Mode.
d. RGY: This selects OSD Tally RGY Mode.
14. Tally Source: The Tally Source may be set as follows:
a. GPI: GPI protocol is selected.
b. TSL: TSL protocol is selected.
15. Port Number: The Network Port Number is 3000.
