vMON-Series
Page 5
CHAPTER 1: Installation
Introduction
Overview
The vMON Series is a full-featured range of slim, free standing video monitors ideal
for mobile trucks, news and transmission control rooms, 4K or 8K production/post-
production and video surveillance applications. These monitors come standard with
in-monitor level metering, selectable video vectorscope/histogram, safe area and
aspect ratio markers, IMD labeling, tally, and built-in color bars, as well as a variety
of picture controls and productive video features such as zoom controls and focus
assist.
The vMON Series consists of 17”, 24” (4K only), 27”, or 32” 4K or 8K monitors
which support a variety of 12G/6G/3G/HD/SD-SDI, HDMI, and SFP+ Cage source
inputs. They support a large variety of professional broadcasting features such as
Audio Metering, Quad View, Waveform, Histogram, and Vectorscope, making them
brilliant monitors in 4K or 8K production workflows.
All standard frame rates and resolutions are supported from 12G-SDI, 6G-SDI, 3G-
SDI, and HDMI input sources, and each SDI input has a looping output. Up to 16
audio channels may be selected for visual monitoring using on-screen bar graph
style level meters. Monitoring speakers on the front panel allow the selected screen
to be audibly monitored, while a 3.5mm headphone jack provides optional private
monitoring.
Safety
Instructions
1. Read, keep, and follow all of these instructions; heed all warnings.
2. Do not use this equipment near water.
3. Use only a dry cloth to clean the equipment.
4. Do not block any ventilation openings.
5. Do not install near any heat source such as a radiator, heat register, amplifier, or
stove.
6. Do not attempt to plug the unit into a two-blade outlet (with only two prongs of
equal width).
7. Protect the power cord from being walked on or pinched, particularly at plug
connection on the equipment and at the socket.
Important:
By design, the supplied AC mains power cord will only plug into a
three-prong grounded outlet for your safety. If the plug does not fit
into the outlet, contact an electrician to replace the obsolete outlet.
