vMON-Series
Page 32
8. Box Display: The Box Display may be turned OFF or ON.
9. Box Center: The Box Center may be turned OFF or ON.
10. Box Mat: This is the color of the filling outside of the Box wire frame. It
may be set to OFF, White, Black, Translucent, Red, Green, or Blue.
11. Box Line Color: The color of the Box wire frame may be set to: White,
Green, Blue, Cyan, Red, or Yellow.
12. Box Line Width: The thickness in pixels of the Box wire frame line may be
set to 4PX or 8PX.
13. Box HStart: The horizontal start position of the Box wire frame may be set
anywhere between 0 and 3840.
14. Box VStart: The vertical start position of the Box wire frame may be set
anywhere between 0 and 2160.
15. Box Width: The horizontal width of the Box wire frame may be set
anywhere between 0 and 3840.
16. Box Height: The vertical height of the Box wire frame may be set
anywhere between 0 and 2160.
Audio Menu
Rotate the U+D Image knob to highlight the Audio selection and press the U+D
Image knob to enter the submenu. This menu allows you to set the various Audio
setups and displays on the monitor. This menu is shown in Figure 2-18.
Use the L+R Volume and U+D Image knobs to travel through the menu and
make changes, as explained in the Menu Navigation section of this chapter.
Figure 2-18: Audio Menu
The items it contains are as follows:
1. Audio Source: The Audio Source can be set to Win1, Win2, Win3, or Win4.
This function is only available in Quad Mode.
2. Left Audio Channel: The Audio source of the left channel can be set to any
