1. Channel Source: The Source of the Closed Captions can be set to SDI1,
SDI2, SDI3, or SDI4.
2. CC Mode: The three CC Mode settings are:
a. OFF: Closed Captions will not be displayed.
b. 708: 708 Closed Captions will be displayed.
c. 608: 608 Closed Captions will be displayed.
3. CC 608: Type CC 1, CC 2, CC 3, or CC 4 Mode 608 Closed Captions may be
selected.
4. CC 708: Service Type 1, 2, 3, 4, 5, 6, or 7 Mode 708 Closed Captions may
be selected.
UMD Menu
Rotate the U+D Image knob to highlight the UMD selection and press the U+D
Image knob to enter the submenu. This menu allows you to set the various UMD
setups and displays on the monitor. This menu is shown in Figure 2-20.
Use the L+R Volume and U+D Image knobs to travel through the menu and
make changes, as explained in the Menu Navigation section of this chapter.
Figure 2-20: UMD Menu
Status
Function
Source
Color
Scope
Assist
Marker
Audio
CC
UMD
System
UMD Display Off
UMD Color White
UMD Character 1 Channel1
UMD Character 2 Channel2
UMD Character 3 Channel3
UMD Character 4 Channel4
UMD ID 0
UMD Screen ID 0
UMD Display ID 0
Baud Rate 38400
UMD Protocol TSL 3.1
VPID/HDMI Status
Config
LED Tally Off
UMD Tally Color RG
Port Number 3000
Tally Source TSL
The items it contains are as follows:
1. UMD Display: The UMD Display may be turned ON or OFF.
2. UMD Color: The color of the UMD Display my be set to Green, Red, White,
or Black.
3. UMD Protocol: The UMD Protocol can be set to:
a. Local: The UMD characters can be set locally.
b. TSL3.1: The UMD characters can be set remotely using TSL3.1
protocol using an RS422 interface, 8-bits, 1 stop bit, even parity,
38400 baud.
