vMON-Series
Page 29
a. OFF: The Waveform measurement is off and will not display.
b. LUMA: The LUMA waveform will display.
c. YCbCr: The YcbCr waveform will display.
d. RGB: The RGB waveform will display.
e. Quad Luma: This will display Quad Luma. This function is only
available in Quad Mode.
2. Waveform Scale: The Waveform Scale may be set to:
a. Digital: The Waveform Scale is displayed numerically.
b. IRE: The Waveform Scale is displayed as a percentage of luminance.
c. Luma PG: The HDR PQ luminance waveform is displayed.
d. Luma HLG: The Luma HLG luminance waveform is displayed.
3. Waveform Alarm: The Waveform Alarm display can be set to any
percentage with the range of 80% to 100%. When the measured waveform
reaches or exceeds this percentage, an alarm will occur and the alarm will be
indicated in red.
4. Waveform Filter: Display of the Waveform Filter may be turned ON or OFF.
5. Vector: This controls the Vector display as follows:
a. OFF: No Vector display
b. 100: The vector illustration is 100% of the display.
c. 75: The vector illustration is 75% of the display.
6. Histogram: This controls the Histogram display as follows:
a. OFF: Turn off the Histogram display.
b. LUMA: Display the brightness histogram.
c. RGB: Display theRGB histogram.
7. Channel Select: This adjustment is only available when the monitor is in
Quad View mode. It controls which channel will be the subject of the
Waveform display. The choices are Channel 1, Channel 2, Channel 3, or
Channel 4.
