vMON-Series
Page 27
5500K, or User 1 to User 6. You may customize the Color Temperature, save
it to a corresponding User Mode (User1 through User6) in a configuration,
assign that configuration to a S1 to S4 Select key, and then use that S1 to
S4 key to load it. Note: After modifying the parameters, be sure to go to the
Config menu and save the Configuration. Otherwise, the S1 to S4 keys will
continue to load the previous Configuration.
18. R Gain: The adjustable range of Red Gain is 0 to 1023. This can only be
adjusted in Color Temperature User mode.
19. G Gain: The adjustable range of Green Gain is 0 to 1023. This can only be
adjusted in Color Temperature User mode.
20. B Gain: The adjustable range of Blue Gain is 0 to 1023. This can only be
adjusted in Color Temperature User mode.
21. R Offset: The adjustable range of Red Gain is 0 to 1023. This can only be
adjusted in Color Temperature User mode.
22. G Offset: The adjustable range of Green Gain is 0 to 1023. This can only be
adjusted in Color Temperature User mode.
23. B Offset: The adjustable range of Blue Gain is 0 to 1023. This can only be
adjusted in Color Temperature User mode.
Image Menu
Rotate the U+D Image knob to highlight the Image selection and press the U+D
Image knob to enter the submenu. This menu will let you set up details about how
the image will be displayed. This menu is shown in Figure 2-14.
Use the L+R Volume and U+D Image knobs to travel through the menu and
make changes, as explained in the Menu Navigation section of this chapter.
Figure 2-14: Image Menu
The items this menu contains are as follows:
1. Backlight: The range of Backlight adjustment is 0 to 100.
2. Aspect Ratio: The available settings are Full Screen, Original Screen and
