vMON-Series
Page 19
Video Payload ID/HDMI Status Menu
Rotate the U+D Image knob to highlight the VPID/HDMI Status selection and
press the U+D Image knob to enter the submenu. This menu will either display
the Video Payload ID/HDMI status for the selected HDMI or SDI source. This menu
is shown in Figure 2-9.
Use the L+R Volume and U+D Image knobs to travel through the menu and
make changes, as explained in the Menu Navigation section of this chapter.
Figure 2-9: VPID/HDMI Status Menu
Status Channel Select Channel 1
Source SDI1
SMPTE Standard Unknown
Color Depth --
Color Format --
Picture Rate --
Scanning Method --
Colorimetry --
Payload ID 00 00 00 00
Function
Source
Color
Scope
Assist
Marker
Audio
CC
UMD
System
VPID/HDMI Status
Config
Link Assignment --
SDI Source
HDMI Source
Status Channel Select Channel 1
Source HDMI
Color Depth --
Color Format --
Colorimetry --
Data Level 00 00 00 00Function
Source
Color
Scope
Assist
Marker
Audio
CC
UMD
System
VPID/HDMI Status
Config
The items these menus contain are as follows:
1. Channel Select: Use this to select the channel on which to view the various
signal parameters.
2. Source: Display of the current input signal.
3. Payload ID: Display of the Payload ID. (SDI only)
