20
ENVIRONMENT PRESERVATION
• The materials of packing are ecological and recyclable.
• The electronic appliances are composed of recyclable, and sometimes harmful materials
for the environment, but necessary to the good running and the safety of the appliance.
INSTALLATION INSTRUCTIONS
The installation must be performed by a qualified electrical contractor.
How to stick the gasket:
The gasket supplied with the hob prevents the intrusion of liquids into the cabinet below.
It’s installation has to be done carefully, in conformity with the following drawing.
Fitting - installing:
• The cut out sizes are:
Glass length
Glass width
Cutting length
Cutting width
Glass
thickness
WIF598
590 mm
520 mm
560 mm
490 mm
4 mm
WIF708
700 mm
520 mm
560 mm
490 mm
4 mm
WIF828
820 mm
520 mm
670 mm
490 mm
4 mm
• Ensure that there is a distance of 50 mm between the hob and the wall or sides.
• The hobs are classified as “Y” class for heat protection. Ideally the hob should be installed
with plenty of space on either side. There may be a wall at the rear and tall units or a wall
at one side. On the other side, however, no unit or divider must stand higher than
the hob.
• The piece of furniture or the support in which the hob is to be fitted, as well as the edges of
furniture, the laminate coatings and the glue used to fix them, must be able to resist
temperatures of up to 100 °C.
• Do not install the hob at the top of a non ventilated oven or a dishwasher.
• Don't throw your appliance with the household refuses
• Get in touch with the waste collection centre of your
commune that is adapted to the recycling of
the household appliances.
Stick the gasket (2) two millimetres from the
external edge of the glass, after removing the
protection tape (3).
