21
J
Auxiliary,
semi-rapid
and rapid
burner
REPLACEMENT OF THE INJECTORS
If the injectors are not supplied they can
be obtained from the “Service Centre”.
Select the injectors to be replaced according
to the “TABLE FOR THE CHOICE OF THE
INJECTORS”.
The nozzle diameters, expressed in
hundredths of a millimetre, are marked on
the body of each injector.
REPLACEMENT OF THE
INJECTORS OF THE COOKTOP
BURNERS
To replace the injectors proceed as follows:
• Remove pan supports and burners
from the cooktop.
• Using a wrench, substitute the
injectors “J” (gs. 2.2a, 2.2b, 2.2c,
2.2d) with those most suitable for the
kind of gas for which it is to be used.
The burners are conceived in such a
way so as not to require the regulation
of the primary air.
J
J
J
J
Fig. 2.2a
Fig. 2.2b
Fig. 2.2d Fig. 2.2c
Triple-ring compact
burner
Triple-ring burnerDual burner
Injector for
inner crown
Injectors
for outer
crown
J
J
