EN
40
ii) When you press touch keys and
(4/5) simultaneously, the hot plate
will switch o quickly.
RESIDUAL HEAT INDICATOR
The power indicator of the hot plate will
display an H when the glass surface
reaches a temperature that could
cause burning.
When this risk disappears,
i) the display switches o (if the device
is in stand by),
ii) or displays 0 (if the appliance is
still running).
Warning:
In a first run, H indication may
appear in a short time on the power
display. This showing is related
with setup operation and it does
not mean the cooking zone is hot.
Warning:
H indication is used for the safety
purposes in any case. Even if the
power is cut o for a long time, after
power on, H indication appears.
SWITCHING OFF THE DEVICE
The device can be switched o at any
time by pressing the general on/o
touch key (1). In standby mode an
H will appear in the zones that are hot.
The rest of the displays will not light up.
Double burner hot plate
If your cooker has this option, the
double burner hot plate offers the
possibility of using the inside ring or
also, in addition, the outside one,
depending on the size of the pot or
pan.
SWITCHING ON THE DOUBLE
HOT PLATE
1 The related hot plate must be
selected.
2 Select the desired power (from
1 to 9) using the touch key or
(4/5).
3 Press the double hot plate touch
key (6) to activate the double
burner. When the double zone will
be activated, double zone indicator
(8) light on.
SWITCHING OFF THE DOUBLE
HOT PLATE
1 The key, by which its double burner
hot plate was switced on previously
is selected.
2 Press the double hot plate touch
key (6) to deactivate the double
burner. The double burner indicator
(8) will light o and the outer ring will
be deactivated
Locking of the touch keys
of the cooking hob
To prevent undesired manipulation
you can lock the entire unit, except
for the on/off touch key, using the
locking touch key (7). This function
is useful for child safety. When the lock
is activated, the lock indicator light (9)
comes on.
However, remember when the touch
control is on, the on/o touch key
(1)allows you to switch it o, even if
the lock is activated (the lock indicator
light (9) on).
On the other hand, if the touch control
is switched o, the locking function
does not allow the on/o touch key
(1) to be used.
To deactivate the locking function,
press the locking touch key (7) once
again. Lock indicator (9) light o and
touch control will be ready for use.
CHILD LOCK (depending on model)
The child lock is dierent and more
complicated than key lock. User can
activate key lock via one sensor. But
child lock need a sensor sequence.
The Child Lock is being used to
prevent children from turning on
the hob.
Activating Child Lock :
1. The hob is switched on via (1)
On/O touch key,
2. Any zone should not be selected.
When any zone is not selected,
(5) Increase power touch key and
(4) decrease power touch key
and minus sensors is hold for 3
seconds at same time. At the end
of this period, a short buzzer sound
is heard
3. After buzzer signal , the (7) locking
touch key is touched (there is no
need to keep press for a long time)
and a long buzzer sound is heard
and the Child Lock will be activated
and all power display shows “L”.
During Child Lock, if user touch any
sensor (Main sensor included) , “L”
will ash on display.
Warning : Child lock status is not
being stored. If the energy of the hob
is butted, child lock status could not
be preserved.
Deactivating Child Lock :
To be able to deactivate Child Lock,
the Child Lock should be activated
before and all power display show “L”
1. (5) Increase power touch key
and (4) decrease power touch
key and minus sensors is hold for
3 seconds at same time. At the end
of the this period, a short buzzer
sound is heard,
2. After buzzer signal , is touched to
the (7) locking touch key (there
is no need to keep press for a long
time) and a long buzzer sound is
heard and the Child Lock will be
de activated and “Indication will
be light o.
Flash Cooking
(Automatic cook start)
This function facilitates cooking as
you do not need to be present while
it is being done. The touch control
pre-programmes the chosen hot
plate at the maximum power and
subsequently lowers it to the desired
power level (which you have selected)
after an approximate amount of time
