ICEMAKER
Turning on the icemaker
Both WRFS26D... and WRFS26S... models have a dispenser
connected icemaker located on the left side of the refrigerator
compartment. The WRFS26S... model also features an
icemaker located on the left side of the bottom freezer
compartment.
Whenever the refrigerator is plugged in after being unplugged,
icemaking is automatically set to On. To turn icemaking Off or
On, see the instructions in Shutting icemaking off.
For the WRFS26S... model the control panel On and Off
icemaking settings apply to both icemakers at the same time.
NOTE: As long as icemaking is turned On in the control panel,
if an icemaker stops production because the ice bin becomes
full, production will resume operation once the ice bin is
cleared of ice.
Dispenser Icemaker Alternate On/Off
The dispenser icemaker is equipped with an On/Off button in
the upper left corner. You may turn the icemaker On or Off
by pressing the button for 3 seconds. When turned On, the
indicator light next to the button will illuminate. See detailed
instructions on the label found on the side of the dispenser
icemaker.
In case the icemaker doesn’t work
• Did you wait for 12 hours after installation of the water supply
line before making ice?
• Is the water line connected and the shut-off valve opened?
• Did you manually stop the ice making function?
• Is the freezer temperature too warm? Try setting the freezer
temperature lower.
In case of power failure
In the event of a lengthy power failure, remove ice cubes in
the storage bin as the ice may melt and ow down to the ice
dispenser and leak out.
Place bin back in the icemaker assembly.
Shutting icemaking off
Important!
If you do not intend to use any ice cubes for longer than
one week (e.g. because you are going on holiday), shut off
icemaking for that period to prevent ice cubes from freezing
together.
1. To turn OFF :
Press and hold Water and Ice Type buttons at same time
for 3 seconds until Ice Off illuminates in the control panel
display.
To turn ON :
Press and hold Water and Ice Type buttons at same time
for 3 seconds until Ice Off ceases to illuminate in the
control panel display.
2. Empty and clean the ice cube bin.
To remove ice bin from dispenser icemaker, grasp front of
ice bin and pull forward.
To remove freezer ice bin, pull freezer drawer all the way
forward and lift ice bin up and out of pullout drawer.
NOTE: There is a ngerhold indentation on the bottom front of
the dispenser ice bin for ease of bin removal.
3. Return the ice cube bin into position.
NOTE: The ice bin should be emptied any time the icemaker
is turned off.
USING YOUR REFRIGERATOR
