HOW TO REMOVE THE FREEZER DRAWER
WARNING:
Use two or more people to remove and install
the freezer drawer. Failure to do so can result in personal
injury, product or property damage.
1. Take out the ice bin rst, and then take out the upper
freezer drawer by lifting it up.
2. Remove lower freezer basket by pulling up and tilting
toward refrigerator until it can be removed from the freezer
drawer/door assembly.
3. Push the rail support locking tabs to release the main
freezer drawer rails from the cabinet while slightly pulling
the exterior freezer drawer outwards, so that the locking
tab does not return to the locked position. The locking
tabs are located in the freezer compartment to the rear of
the main rail assembly (which is attached to main exterior
freezer drawer) as shown in the illustration below.
4. Pull exterior freezer drawer to fully disengage the rail
assembly from the unit. Use 2 people for this task as the
door is heavy and awkward to handle.
CAUTION:
Do not hold the handle when removing or
replacing the drawer. The handle may come off and it
could cause personal injury.
5. Place the door on a non-scratch surface.
REFRIGERATOR INSTALLATION
Locking Tab
13
