PPA T27
20
Personal PA Receiver (Model PPA R37-8)
Dimensions: 4.1” x 2.85” x 1.38” (104 x 72 x 35 mm)
Weight: 4.6 oz (130 g) with batteries. 2.6 oz (73 g) without batteries
Color: Black
Battery Type and Life:
Two (2) AA non-rechargeable alkaline batteries (BAT 001-2),
approx. 50 hours battery life
Two (2) AA rechargeable NiMH batteries (BAT 026-2), 1500 mAh,
approx. 32 hours battery life
Current Consumption: 42 mA nominal
Temperature Range: – 0 to 50 °C
Channels: 8, accessed via rotary knob on top of unit
Operating Frequencies: 72.1, 72.3, 72.6, 72.8, 74.7, 75.4, 75.7, 75.9 MHz
Modulation: FM, +/- 75 kHz peak deviation
De-Emphasis: 75 µS
LED Indicator: Power: Green; Low Battery: Flashes Green; Sleep mode: Fade-
on,Fade-o
Sensitivity: 2 µV at 12 dB Sinad with squelch defeated
Input Overload: 100 mV
Frequency Response: 200 – 15 kHz
Signal-to-Noise Ratio: 65 dB min @ 100 uV
Receive Antenna: Integral with earphone/headphone cord
Audio Output: 35 mW max, peak into 16 Ω
Output Connector: 3.5 mm stereo/mono phone jack
Included Earphone: Earbud-type with foam cushion, 3.5 mm plug, 32 Ω
Sleep Mode:
Enters sleep mode after approximately 6 mins of no RF signal,
returns to normal operation when a transmitter is re-established on
same channel
Approvals: FCC, Industry Canada, RoHS, WEEE
Warranty: Lifetime PLUS Limited Warranty; 90 Days on most accessories
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
