28
FM+ C
Deviation
± 75 kHz maximum
Pre-Emphasis
75 µsec
RF Field Strength
Does not exceed 80 mV/m at 3 m
Compatible Antennas
ANT 005, ANT 021, ANT 024, ANT 025, ANT 028, ANT 029, ANT 034
Refer to Williams AV’s 72 MHz Antenna Selection Install Guide for FCC-compliant antennas for this product.
Transmission Range
Up to 1000 ft (304 m) with ANT 005 coaxial antenna mounted on rear chassis F-connector
RF Outputs
(1x) #10-32 stud connector in center of unit (pcb mounted)
(1x) F-connector on rear chassis
RF Transmit (RF) Power
Indicator
1 OLED On Air Indicator with 4 states indicating power level Off, Low, Medium and Full Power.
RF Time Out (sleep mode)
30 min. duration, 4 hr. duration, or Always On; selected via web interface. When audio drops below
-18 dB, the selected duration begins, and when it expires the unit stops transmitting and goes into
a low-power (“sleep”) mode. Any button press or resumption of audio above -18 dB “awakens” the
unit and it begins transmitting again.
Audio Section
Audio Inputs
(1x) Combination 3-pin XLR, 1/4” (TRS) jack for balanced or unbalanced line level, or balanced or
unbalanced microphone with selectable phantom power. Optional RJ-45 Dante Input (“D” models
only).
Audio Processor Functions
DSP based; Compression: 1:1, 1.5:1 or 2:1; High-pass and Low-pass Filter Frequency control,
Music, Voice and Hearing Assistance Audio Presets
Frequency Response
31-16000 Hz, ±3 dB (re: 1 kHz) (“Music” Audio Preset)
Signal-to-Noise Ratio
64 dB (typical) Transmitted RF @ 1kHz
Total Harmonic Distortion
Less than 0.25% @ 1 kHz (RF output)
Common Mode Rejection
>57 dB @ 1 kHz, Mic or Line mode
Audio Input Gain Adjust
Adjustable from +24dB to -60 dB, in 1dB steps from front screen or web interface.
Phantom Power
14.4 VDC applied through 2.2 kΩ resistors to analog combo jack: Pin 2 and Pin 3 on XLR jack, or tip
and ring on 1/4” TRS jack
Audio Level Display
Front screen bar graph display, each segment representing 3dB. It ranges from -18 (1 segment lit) to
+12dB (10 segments lit). Over-range warning is indicated by ‘OVLD’ and flashing empty bar.
Headphone Output
1/4” TRS stereo jack, mono signal, 7.8mW total power with 33 Ω.
Dante Input
(1x) RJ-45 jack, only available on FM T55CD.
Input Level (Bal or Unbal)
(at Audio Input Gain = 0dB)
at 1 kHz
Nominal (@ 7th Segment Lit)
Indicated by Audio Level Display
Overload Warning
Indicated by Audio Level
Display “OVLD”
Absolute Max. Rating
Stresses above these ratings
may cause permanent dam-
age or degrade reliability�
Microphone
-45 dBV (5.6 mV RMS) -20 dBV (100 mV RMS) +20 dBV (10.0 V RMS)
Line
-8.4 dBV (380 mV RMS) +16 dBV (6.5V RMS) +20 dBV (10.0 V RMS)
Approvals
FCC, RoHS3, WEEE, Industry Canada
Warranty
2-year parts and labor
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
**
Stresses above these ratings may cause permanent damage. Exposure for extended periods may degrade reliability.
This device complies with Industry Canada licence-exempt RSS standard(s) and FCC part 15.105[b] for the United States.
Operation is subject to the following two conditions: [1] this device may not cause interference, and [2] this device must accept
any interference, including interference that may cause undesired operation of the device.
Remote Telnet Control
A separate Telnet Control Guide is available for download. It is located on the WilliamsAV website, on the product
model page, under the Download Tab.
