NSF International requires the following water connection:

1. A quick disconnect or additional coiled tubing (at least 2x the depth of the unit) so that the machine

can be moved for cleaning underneath.

2. Thisequipmentistobeinstalledwithadequatebackowprotectiontocomplywithapplicable 

federal, state and local codes..

3. Waterpipeconnectionsandxturesdirectlyconnectedtoapotablewatersupplyshallbesized, 

installed and maintained in accordance with federal, state, and local codes.

1

Important Safeguards/Symbols

Service Manual, TCC

Thisapplianceisdesignedforcommercialuse.Anyservicingotherthancleaningandmaintenance

shouldbeperformedbyanauthorizedWilburCurtisservicecenter.

 •DoNOTimmersetheunitinwateroranyotherliquid

 •Nevercleanwithscouringpowders,bleachorharshchemicals.

Symbols:

WARNINGS – To help avoid personal injury Important Notes/Cautions

Sanitation Requirements

Curtis TCC Units are Factory Pre-Set and Ready to Go… Right out of the Box.

Generallytherewillneverbeareasontochangefactorysettings.However,shouldyouneedto

makeslightadjustmentstomeetyourteaneeds,adjustmentinstructionsareprovidedlaterinthis

manual.

 SystemRequirements:

•WaterSource30–90PSI(MinimumFlowRateof1GPM).Ifincomingwatersupplyisgreater

than90PSI,additionalregulationisrequiredtomeettherange.

•Waterpipeconnectionsandxturesdirectlyconnectedtoapotablewatersupplyshallbe

sized,installedandmaintainedinaccordancewithfederal,state,andlocalcodes.

SETUP STEPS

Theunitshouldbelevel(lefttorightandfronttoback),locatedonasolidcountertop.Connecta

waterlinefromthewaterltertotheTCCserver.NOTE:Sometypeofwaterltrationdevicemust

beusedtomaintainatrouble-freeoperation.(Inareaswithextremelyhardwater,wesuggestthat

asedimentaryandtaste&odorlterbeinstalled.)Thiswillprolongthelifeofyoursystemand

enhanceteaquality.

INSTALLATION

1.Removedispenserfromcarton.

2.Runawaterlinetotheinletttingbehindthedispenser.Flushthenewwater-

line to remove foreign particles.

3.Connecta¼”aredexibleorcopperwaterlinetothemalettingontheback

of the dispenser.

4.Locatethewatersupplyvalvebehindtheunittoverifypositionisturnedon.

CAUTION:Werecommendedthatthewatersupplyvalve,behindunit,beturnedoffduring

non-business hours.

Wilbur Curtis Company, inC.

ModelsIncluded

•TCC1

•TCC2

•TCC3

NOTE:Watersource

pressure must be a

minimumof30PSI

pressure at all times

toinsurethequalityof

the of the product.

5.CleanouttheteaconcentratesystembeforeusingtheTCCserver.UseaBag-in-Box

stylecleaningsolutiontosimplifythecleaningprocedure.AcleanerlikeBevClean

beveragelinecleanercomesina3gallonbag-in-boxthatconnectsdirectlytoyour

bag-in-boxsystemforlinecleaning(http://bevclean.com).

 a.Removethequickdisconnectfromtheteaconcentratebag.

 b.PlacetheBIBcleanercontainernexttotheTCCteadispenser.Pullthespout 

 fromthecleanerboxthroughthemarkedarea.Removethecleartravelcapfrom

 spout.Don’tworryaboutcleanerspillingwhenthecapisremoved.Thecaphas 

an internal seal.

 c. SnaptheQCDbagconnectorontothebagspout.

OFF

ON

ISO 9001:2008 REGIS-

TERED

WILBUR CURTIS CO., INC.

6913 West Acco Street

Montebello, CA 90640-5403

For the latest information go

to www.wilburcurtis.com

Tel: 800-421-6150

Fax: 323-837-2410
