WiiM Amp Pro User Manual Version 1.2 1/21/2025
9
WiiM Music Streaming
Platform
Yes
CPU
Quad Core A53
DRAM
512 MB
Flash
512 MB
Audio Input Port
HDMI ARC:
⚫ Up to 192kHz/24-bit.
⚫ Supports Stereo PCM and Dolby Digital,
but not DTS.
Optical In:
⚫ Up to 192kHz/24-bit.
⚫ Supports Stereo PCM and Dolby Digital,
but not DTS.
Line In:
⚫ 2 Vrms
⚫ Analog signal, converted to digital via
ADC (up to 192kHz/24-bit)
Audio Output Port
Passive Speaker Terminals/Banana (x2)
USB Out:
⚫ Up to 192kHz/24-bit
⚫ UAC 2.0
⚫ DC 5V/1.5A power output
Note: The USB Out port currently does not support
Subwoofer Output (Sub Out). This feature will be
supported in the future.
Sub Out (2.0 Vrms)
External USB Storage
Access personal media library and use it as a media
server for other WiiM and DLNA devices. Support
FAT32, NTFS, and EXT4 file systems.
LED
⚫ Three-color status LED - Red, Green, and White
⚫ Six volume LEDs
Control
Volume knob, play/pause, setup, and more
Weight
1.84 kg (4.1 lbs)
Dimension
7.48" x 7.48" x 2.48" (190 mm x 190mm x 63 mm)
Power Input
100-240V, 50/60Hz AC Power
