9
NOTE: To ensure good performance, do not obstruct top vent
airflow. If cabinets are larger than 14" (35.6 cm) but no more than
15" (38.1 cm), use the bump out mounting kit replacing the
mounting plate from the wall. The bump out mounting kit
(part # W11185746) is not provided but can be purchased from
Whirlpool.
To order, see the "Online Ordering Information" section of the
Quick Start Guide.
For cabinets with other dimension’s, we suggest selecting other
Whirlpool Products.
Electrical Requirements
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Observe all governing codes and ordinances.
Required:
� A 120 V, 60 Hz, AC only, 15 or 20 A electrical supply with a
fuse or circuit breaker.
Recommended:
� A time-delay fuse or time-delay circuit breaker
� A separate circuit serving only this microwave oven
GROUNDING INSTRUCTIONS
For a grounded, cord-connected appliance:
This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for
electric current. This appliance is equipped with a cord having
an equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local
codes and ordinances.
WARNING: Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in
doubt as to whether the appliance is properly grounded. Do
not modify the plug provided with the appliance: if it will not fit
the outlet, have a proper outlet installed by a qualified
electrician.
SAVE THESE INSTRUCTIONS
This device complies with Industry Canada ICES-001.
PREPARE MICROWAVE OVEN
HOOD
Prepare Microwave Oven Hood
Combination
WARNING
Excessive Weight Hazard
Use two or more people to move and install or uninstall
appliance.
Failure to do so can result in back or other injury.
1. To avoid possible damage to the work surface, cover the work
surface.
2. Remove cardboard plate from the outer foam in the carton. It
is for upper-cabinet and wall installation.
3. Remove exhaust vent covers from the upper foam in the
carton, they are used for upper-cabinet and wall installation.
4. Remove the screw pack from the upper foam in the carton.
5. Remove the literature pack from the upper foam in the carton.
6. Remove shipping materials, tape and film from microwave.
7. Remove the mounting plate from the upper foam in the carton.
8. Remove glass turntable from the upper foam in the carton.
9. Remove the damper from the bottom foam in the carton.
10. Remove the turntable support ring from the bottom foam in the
carton.
11. Tape the microwave oven door closed so that the door does
not swing open while the microwave oven is being handled.
Installation Types
This microwave oven is designed for adaptation to the following
three types of ventilation, choose one type before installation.
NOTE: For roof venting and wall venting, charcoal filter is not
necessary, uninstall the charcoal filter before use. See the
"Complete Installation" section for details.
Recirculation (Factory Default Setting)
