17
NOTES:
� Some upper cabinets may require bolts longer or shorter than
3" (7.6 cm). Longer or shorter bolts are available at most
hardware stores.
� Overtightening bolts may warp the top of the microwave oven.
To avoid warping, wood filter blocks (installer to provide) may
be added. The blocks must be the same thickness as the
space between the upper cabinet bottom and the microwave
oven.
A
A. Bolts
� Avoid damage to the mounting nut, screw the bolts into the
mounting nut holes around 15–20 mm by hand first, make sure
the bolts thread in properly. Then tighten with tools.
15-20 mm
A
B
A. Bolt
B. Mounting Nut
11. Connect vent to damper assembly.
A B
A. Vent
B. Damper assembly (under vent)
Complete Installation
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
1. Plug microwave oven into grounded 3 prong outlet.
2. Reconnect power.
3. Check the operation of microwave oven by placing 1 cup
(250 mL) of water on the cavity and programming a cook time
of 1 minute at 100% power. Test vent fan and exhaust by
operating the vent fan.
4. If the microwave oven does not operate:
� Check that a household fuse has not blown, or that a
circuit breaker has not tripped. Replace the fuse or reset
the circuit breaker. If the problem continues, call an
electrician.
� Check that the power supply cord is plugged into a
grounded 3 prong outlet.
5. See the quick start guide for more informations.
The installation is now complete.
Save Installation Instructions for future use.
A
A. 13.7" (34.8 cm) is the height from the highest point of the
stove to the bottom of the microwave oven
